The LionC is a zero emission school bus that offers a more sustainable and safe transportation solution for your students and drivers.
Its 18″ wide aisle, composite body and modular skirt design ensure both enhanced safety and comfort inside the bus, and operational efficiency and repairs.
Top Speed – 95 km/h
Maximum Power – 250 kW | 335 CV
Maximum Torque – 1,800 ft-lb | 2,500 Nm
Range – Base Model : Up to 200 km Range Plus Model : Up to 240 km
Battery capacity – Base Model : 159 kWh Range Plus Model : 212 kWh
Motor & Invertor – SUMO MD | Dana TM4
Transmission – Direct drive | No transmission
Charging Time* –2.5 hours
Plug-in Charging location – Front
Front Axle – 10,000 lbs. | 4,535 kg
Rear Axle – 21,000 lbs. | 9,525 kg
Suspension
Standard | Front and rear leaf springs
Optional | Rear air springs
Braking system
Standard | Hydraulic service brakes, cable parking brake
Optional | Air brakes (service and parking)
Capacity – 72 passengers
Vehicle Length – 473 in. | 1,200 cm
Vehicle Width – 96 & 102 in. | 244 & 259 cm
Vehicle Height – 122 in. | 310 cm
Wheelbase – 278 in. | 706 cm
Gross Vehicle Weight Rating – 31,000 lbs. | 14,061 kg
